SPLIT TYPE ULTRASONIC LEVEL METER..
|
|
GLP-4A WALL MOUNTED SPLIT TYPE ULTRAONSIC LEVEL METER | GLP-4B PLATE SPLIT TYPE ULTRAONSIC LEVEL METER |
I、OVERVIEW
◇24VDC\220VAC the power supply
◇Digital installation assistant analysis
◇The LCD display, and keystrokes
◇Simulation settings or site settings
◇Remove the false measurement
◇RS485 output
◇The standard output is 4-20mA
◇Piezoelectric wave rushed security protection
Split type ultrasonic level meter make as two times operation and display and transmitter in complicated situations ( can not maintainance and debugging).it can save cost for the project, also suit for complex measure needs in oil,chemical and coal.
II、MAIN TECHNICAL PARAMETERS
Range | 0-30m |
Accuracay | ±0.25%F.S，±0.5F.S |
Resolution Ratio | ≥10m,5mm ＜10m,1mm |
Beam Angle | <10@3dB |
Frequency | ~40KHZ |
Blind Zone | 0.3-0.7m |
Voltage | 24VDC \220VAC |
Output | 4~20mA、six way programmable communication |
Display | LCD backlight display、button |
Temperature Compensation | ships insi\sensor compensation |
Environment Temperature | -20~+60℃ |
Process Temperature | -30~+80℃ |
Process Pressure | 0.5~2BAR |
Installation Conenction | M66X3 |
Process Connection | PG13.5 |
Protection Grade | IP66 |
Shell Material | ABS\PA6 GF30 |
Weight | probe 1.1KG、host 1KG |
III、Size Chart（unit：mm）
1、Wall Mounted split type
![S2$89}E29I)TB9E_{X]LS`T.png](/en/Uploads/ueditor/image/20170511/59143aa585510.png "59143aa585510.png")
2、Plate Split Type
